10mm² "H" Shape Connector
| Part No | Material | Conductor Size | Weight | Conductır Diameter | Quantity | Actions |
|---|---|---|---|---|---|---|
| ET.C.TKH.10 | Cu | 10mm² | 0,02/Pc | 10 mm² |
|
|
| ET.C.TKH.120 | Cu | 120mm² | 0,09/Pc | 120 mm² |
|
|
| ET.C.TKH.120150 | Cu | 120mm² | 0,10/Pc | 150 mm² |
|
|
| ET.C.TKH.150 | Cu | 150mm² | 0,10/Pc | 150 mm² |
|
|
| ET.C.TKH.150185 | Cu | 150mm² | 0,12/Pc | 185 mm² |
|
|
| ET.C.TKH.16 | Cu | 16mm² | 0,03/Pc | 16 mm² |
|
|
| ET.C.TKH.185 | Cu | 185mm² | 0,13/Pc | 185 mm² |
|
|
| ET.C.TKH.185240 | Cu | 185mm² | 0,13/Pc | 240 mm² |
|
|
| ET.C.TKH.240 | Cu | 240mm² | 0,17/Pc | 240 mm² |
|
|
| ET.C.TKH.2535 | Cu | 25mm² | 0,04/Pc | 35 mm² |
|
|
| ET.C.TKH.35 | Cu | 35mm² | 0,04/Pc | 35 mm² |
|
|
| ET.C.TKH.3550 | Cu | 35mm² | 0,04/Pc | 50 mm² |
|
|
| ET.C.TKH.50 | Cu | 50mm² | 0,03/Pc | 50 mm² |
|
|
| ET.C.TKH.5070 | Cu | 50mm² | 0,05/Pc | 70 mm² |
|
|
| ET.C.TKH.70 | Cu | 70mm² | 0,04/Pc | 70 mm² |
|
|
| ET.C.TKH.7095 | Cu | 70mm² | 0,09/Pc | 95 mm² |
|
|
| ET.C.TKH.95 | Cu | 95mm² | 0,10/Pc | 95 mm² |
|
|
| ET.C.TKH.95120 | Cu | 95mm² | 0,09/Pc | 120 mm² |
|
| Part No | Material | Conductor Size | Weight | Conductır Diameter | Quantity | Actions |
|---|---|---|---|---|---|---|
| ET.CS.TKH.10 | CuSn | 10mm² | 0,02/Pc | 10 mm² |
|
|
| ET.CS.TKH.120 | CuSn | 120mm² | 0,09/Pc | 120 mm² |
|
|
| ET.CS.TKH.120150 | CuSn | 120mm² | 0,10/Pc | 150 mm² |
|
|
| ET.CS.TKH.150 | CuSn | 150mm² | 0,10/Pc | 150 mm² |
|
|
| ET.CS.TKH.150185 | CuSn | 150mm² | 0,12/Pc | 185 mm² |
|
|
| ET.CS.TKH.16 | CuSn | 16mm² | 0,03/Pc | 16 mm² |
|
|
| ET.CS.TKH.185 | CuSn | 185mm² | 0,13/Pc | 185 mm² |
|
|
| ET.CS.TKH.185240 | CuSn | 185mm² | 0,13/Pc | 240 mm² |
|
|
| ET.CS.TKH.240 | CuSn | 240mm² | 0,17/Pc | 240 mm² |
|
|
| ET.CS.TKH.2535 | CuSn | 25mm² | 0,04/Pc | 35 mm² |
|
|
| ET.CS.TKH.35 | CuSn | 35mm² | 0,04/Pc | 35 mm² |
|
|
| ET.CS.TKH.3550 | CuSn | 35mm² | 0,04/Pc | 50 mm² |
|
|
| ET.CS.TKH.50 | CuSn | 50mm² | 0,03/Pc | 50 mm² |
|
|
| ET.CS.TKH.5070 | CuSn | 50mm² | 0,05/Pc | 70 mm² |
|
|
| ET.CS.TKH.70 | CuSn | 70mm² | 0,04/Pc | 70 mm² |
|
|
| ET.CS.TKH.7095 | CuSn | 70mm² | 0,09/Pc | 95 mm² |
|
|
| ET.CS.TKH.95 | CuSn | 95mm² | 0,10/Pc | 95 mm² |
|
|
| ET.CS.TKH.95120 | CuSn | 95mm² | 0,09/Pc | 120 mm² |
|
