Flexible Circular Copper Braid Bond (Insulated)
Code: ET.İCSY.SWP.10200.06 +15 variants- Material Type
- Copper
- Conductor Type
- Flexible
- Coating Type
- Insulated
Flexible Flat Tinned Copper Braid Bond
- Product code
- ET.CS.FBP.121200.06 and 15 variants
- Material Type
- Copper
- Conductor Type
- Flexible
- Coating Type
- Tinned
- Part No
- ET.CS.FBP.121200.06
- Material
- CuSn
- Weight
- 0,01/Ad
- Weight 2
- 0,01/Pc
- Length
- 200 mm
- Cross Section
- 6mm²
- Assembly Size
- 6 mm
Pricing is quoted according to project scope, size and quantity.
Technical specifications
16 product codes| Material Type | Conductor Type | Coating Type | Part No | Material | Length | Cross Section | Assembly Size | Weight 2 | Quote |
|---|---|---|---|---|---|---|---|---|---|
| Copper | Flexible | Tinned | ET.CS.FBP.121200.06 | CuSn | 200 mm | 6mm² | 6 mm | 0,01/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.121400.06 | CuSn | 400 mm | 6mm² | 6 mm | 0,02/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.152200.06 | CuSn | 200 mm | 10mm² | 6 mm | 0,02/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.152400.06 | CuSn | 400 mm | 10mm² | 6 mm | 0,04/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.202200.08 | CuSn | 200 mm | 16mm² | 8 mm | 0,03/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.202400.08 | CuSn | 400 mm | 16mm² | 8 mm | 0,06/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.253200.08 | CuSn | 200 mm | 25mm² | 8 mm | 0,05/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.253400.08 | CuSn | 400 mm | 25mm² | 8 mm | 0,10/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.254200.08 | CuSn | 200 mm | 35mm² | 8 mm | 0,08/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.254400.08 | CuSn | 400 mm | 35mm² | 8 mm | 0,16/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.305200.10 | CuSn | 200 mm | 50mm² | 10 mm | 0,10/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.305400.10 | CuSn | 400 mm | 50mm² | 10 mm | 0,20/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.306200.10 | CuSn | 200 mm | 70mm² | 10 mm | 0,13/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.306400.10 | CuSn | 400 mm | 70mm² | 10 mm | 0,25/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.405200.10 | CuSn | 200 mm | 95mm² | 10 mm | 0,19/Pc | |
| Copper | Flexible | Tinned | ET.CS.FBP.405400.10 | CuSn | 400 mm | 95mm² | 10 mm | 0,37/Pc |
This product code or size is not in the list. For special sizes write to us.
Product description
12x1x200mm Tinned Flexible Flat Copper Braid Bond M.6
